Custom Setting Types

When none of the built in setting types fits, you can add your own. A setting type has up to three parts:

1. A PHP class that declares the type and its options, used in block and section schemas.
2. An editor field, the input shown in the settings panel for that type.
3. An optional transformer that turns the stored value into what your Blade views receive.

This page builds a star rating setting.

The Setting Class

Extend BagistoPlus\Visual\Settings\Base and give the type a name:

namespace App\Visual\Settings;

use BagistoPlus\Visual\Settings\Base;

class StarRating extends Base
{
    protected static string $type = 'star_rating';

    public function max(int $max): static
    {
        $this->meta['max'] = $max;

        return $this;
    }
}

Everything you put in $this->meta reaches the editor field as a key of field. Here, max(5) gives the field field.max === 5. The methods of Base all work on your type too, such as default(), info(), localized() and visibleIf().

Use it in a schema like any other setting:

use App\Visual\Settings\StarRating;
use BagistoPlus\Visual\Settings\Text;

public static function settings(): array
{
    return [
        Text::make('author', 'Author'),
        StarRating::make('rating', 'Rating')->max(5)->default(4),
    ];
}

The class can live anywhere your app autoloads. Visual does not need it to be registered.

The Editor Field

Register a field for the type in your editor script. See Loading Editor Assets to load it.

import StarRatingField from './StarRatingField.vue';

document.addEventListener('visual:editor:ready', (event) => {
  const { editor } = event.detail;

  editor.ui.registerPropertyField({
    type: 'star_rating',
    render: StarRatingField,
  });
});

type must match the $type of your PHP class. Without a registered field, the settings panel shows "Unknown field type" in place of the input.

The field is a Vue component used with v-model. It receives:

• field: the setting as declared in PHP, with id, label, default, info and your own options such as max.
• modelValue: the current value. It can be empty, for example on a block saved before the setting existed, so fall back to field.default.

It emits update:modelValue with the new value. The preview updates and the value is saved to the draft right away.

<!-- StarRatingField.vue -->
<script setup>
import { computed } from 'vue';

const props = defineProps({
  field: Object,
  modelValue: Number,
});

const emit = defineEmits(['update:modelValue']);

const stars = computed(() => props.field.max ?? 5);
const current = computed(() => props.modelValue ?? props.field.default ?? 0);
</script>

<template>
  <div class="star-rating">
    <label>{{ field.label }}</label>
    <div>
      <button
        v-for="n in stars"
        :key="n"
        type="button"
        :aria-pressed="n <= current"
        @click="emit('update:modelValue', n)"
      >
        {{ n <= current ? '★' : '☆' }}
      </button>
    </div>
  </div>
</template>

The field renders its own label. The settings panel only adds the info text below it.

Plain DOM Field

render can also be a function. It receives { field, value, onChange } and returns an element:

editor.ui.registerPropertyField({
  type: 'star_rating',
  render: ({ field, value, onChange }) => {
    const input = document.createElement('input');
    input.type = 'number';
    input.min = 0;
    input.max = field.max ?? 5;
    input.value = value ?? field.default ?? 0;
    input.addEventListener('change', () => onChange(Number(input.value)));

    return input;
  },
});

The Transformer

Without a transformer, your views receive the stored value as it is. A transformer lets you clean it up or turn it into an object. It implements SettingTransformerInterface:

namespace App\Visual\Settings;

use BagistoPlus\Visual\Contracts\SettingTransformerInterface;

class StarRatingTransformer implements SettingTransformerInterface
{
    public function transform(mixed $value, array $schema = []): int
    {
        $max = $schema['max'] ?? 5;

        return max(0, min($max, (int) ($value ?? $schema['default'] ?? 0)));
    }
}

$schema is the setting as declared, the same data the editor field receives as field.

Register it for the type in a service provider's boot method:

use App\Visual\Settings\StarRatingTransformer;
use BagistoPlus\Visual\Facades\Visual;

public function boot(): void
{
    Visual::registerSettingTransformer('star_rating', new StarRatingTransformer);
}

The transformer runs when the block renders. The stored value is not changed, so a rating of 9 saved through the editor API is still 9 in the data, and the view receives 5.

Using the Value

In the view, read the setting like any other:

<div {{ $section->editor_attributes }}>
    <p>{{ $section->settings->author }}</p>
    <p>{{ str_repeat('★', $section->settings->rating) }}</p>
</div>
